Pull Cord Cable Manufacturers
Application :
For emergency stop and safety, Pull Cord Cables are used with the Pull Cord switches which are installed along with the conveyor belt in case of an emergency.
Pull cord wire, diameter approximately 5-6 mm galvanized steel wire rope with Heavy Duty PVC cover specially extended for material handling industry.
Specifications :
- Conductor Material: Multi-stranded Zinc coated Galvanized Steel wire to make rope
- Jute Rope: One Jute rope bunched with the multi strands of Galvanized Steel wires
- Insulation (1st): Extruded PVC type-A of IS ; 5831-1984
- Insulation (2nd): Extruded PVC type-A of IS ; 5831-1984
- Color: Orange / Red
- Wire Rope size : 42 x 0.30 mm
Construction Chart:
| No. of diameter of insulation | Construction with 1 Jute thread | Approx diameter of the conductor | Nominal thickness of 1st insulation | Nominal thickness of 2nd insulation | Approx overall diameter of wire | Pull force |
| Nos/mm | Nos x strands | mm | mm | mm | mm | Kg m/s2 |
| 42 / 0.30 | 6 x 7 / 0.30 | 2.8 | 0.40 | 0.70 | 5.00 | 180 |
| 42 / 0.30 | 6 x 7 / 0.30 | 2.8 | 0.65 | 0.70 | 5.50 | 185 |
| 42 / 0.30 | 6 x 7 / 0.30 | 2.8 | 0.90 | 0.70 | 6.00 | 190 |
| 42 / 0.30 | 6 x 7 / 0.30 | 2.8 | 1.40 | 0.70 | 7.00 | 205 |
We are a leading Pull Cord cable manufacturer. Pull cord also known as rope operated emergency is used as a safety switch to stop the conveyor belt in case of emergency.
The Pull Cord is an emergency switch used to stop the belt conveyor instantly when an accident occurs. When an accident occurs or for the normal corrective maintenance, workers can Pull Cord at any position along with the belt to stop the belt conveyor. It is widely used in various belt conveyor equipment for Steel, Aluminium, Power, Coal, Cement, `Building Materials, Mining, Electricity, Port, Metallurgy and Chemical Industries.
