Applications:

For use in magnet crane, Used in steel plant, material handling and coal handling, conveyor belts and mobile machines, overhead crane & EOT cranes

Specifications:

Conductor: Annealed Tinned Copper conductor having Class-5 flexibility as per IS:8130-1984

Separator Tape: Polypropylene tape may be provided over the conductor

Insulation: Heat resistant flexible heavy duty Elastomeric compound type IE-1 or IE-2 of IS:6380-1984 namely EPR Rubber

Fillers: Synthetic fibre or natural rubber provided for strengthening of the cores and proper round shape of the cable

Braiding: Cotton or Nylon Braiding provided between Inner and Outer sheath for strengthening the cable

Sheaths: Heavy duty Heat resistant Flexible  Elastomeric compound type SE-3 or SE-4 of IS: 6380-1984 namely PCP/CSP Rubber with HOFR properties (Heat and Oil resistant Flame Retardant)

Sizes available: 1.0 sq mm to 400 sq.mm from Single Core to Multi-Core

Voltage grade:  1100 volts

Applicable Standards:  IS 9968 (pt-1) , IS: 6380-1984, IS:8130-1984
