High Temperature Resistant Non Flammable Cables

• Applicable Standards : JSS: 51034, IS: 9968 (Pt-1), IS:8130-1984, BS:5308 (Pt-2) & IS:1554 (Pt-1)
• Voltage grade: upto 1100 volts
• Conductor size: 0.50, 0.75, 1.0, 1.5, 2.5, 4, 6, 10, 16, 25 sq.mm up to 240 sq.mm
• Conductor Materials: Annealed Bare Copper / Tinned Copper/ Silver plated Copper and Nickel plated Copper
• Heat Barrier Tape: Ceramic Glass Mica tape / Kapton Tape /Polyimide Tape
• Insulation : PTFE (260 deg C), FEP  (205 deg C), Silicone Rubber(180 deg C), Fiber Glass (600 deg C), Ceramic Glass Mica (800 deg C)
• Screening / Shielding : Aluminium-Mylar tape with ATC drain wire / Silver Plated Copper wire braided / Nickel Plated Copper wire braided
• Armouring : Stainless Steel wire Braided type Flexible
• Inner / Outer Sheath : PTFE (260 deg C), FEP  (200 deg C), Silicone Rubber(180 deg C), Asbestos Yarn (400 deg C), Fiber Glass (600deg C), Ceramic Glass Mica (800 deg C)
• Maximum Temperature with Standing Capacity  : upto 800 deg C

SPECIAL FEATURES

• Available in multiple Insulations having different properties & various temperature range.
• Available  from -73 deg C to 800 deg C range
• Hi Di-electric Strength
• Excellent Flame and Heat Resistant properties
• Available with Non-Flammable properties
• Available both Screen & Unscreen type
• Available both Armoured and Unarmoured type
• High Insulation Resistant
• Flexible and versatile
• High Mechanical strength
• U.V. Resistant
• Oil, Chemical, Moisture and Corrosion Resistant
• Excellent Thermal stability
• Halogen-Free Insulating materials such as PTFE / FEP/ ETFE / Silicone Rubber

 SPECIAL  INSULATING  MATERIALS

INSULATIONS	TEMPERATURE RANGE	PROPERTIES
Alumina Fiber	-73 deg C to 1200 deg C	Excellent Temperature Resistant
Ceramic Fiber	-73 deg C to 800 deg C	Excellent Temperature Resistant
Ceramic Glass Mica	-70 deg C to 800 deg C	Excellent Heat Resistant
Polyamide	-267 deg C to 310 deg C	Thin insulation, different colors available, Flame retardant
PTFE	-100 deg C to 260 deg C	High temperature resistant, Non-Flammable, Chemical and Oil resistant, excellent Di-electric strength
FEP	-80 deg C to 200 deg C	Chemical and Oil resistant, High Di-electric strength
Silicone Rubber	-40 deg C to 180 deg C	Highly flexible, Radiation resistant, high temperature resistant
Fiber Glass Yarn	-70 deg C to 600 deg C	High temperature resistant
Asbestos Yarn	-70 deg C to 400 deg C	High temperature resistant, good abrasion resistant

HTC-909-300

Sintered PTEF – Sintered PTEF – S.S. Wire

Specification

• Voltage grade: upto 1100 volts
• Conductor: Bare Copper / Nickel Plated Copper / Silver Plated Copper
• Type: Multi Stranded Flexible
• Core Insulation: Sintered PTFE with Kapton
• Construction: Twisted cores /  Laid up cores
• Outer Sheath:  Sintered PTFE
• Overall Coverage: Fiber Glass Covering [Optional]
• METAL Braiding: Stainless Steel wire mesh for Mechanical protection [Optional]

Other Options

• Aluminium Mylar Tape Shield / Screen with ATC drain wire
• Overall Asbestos Braiding for Better Chemical & Heat Resistance
• Colour coding as per customised requirement
• Sizes available: 0.5 / 1 /1.5 / 2.5 / 4 / 6 / 10 / 16 / 25 sq.mm.
• Number of Cores available: 1C to Multicore as per customised requirement
• Standards applicable: IS: 8130, IS: 1554 (Pt-1), JSS : 51034, BS : 5308 (Pt-1)

HTC-918-400

Sintered PTFE – Fiber Glass – Fiber Glass – S.S. Wire

Specification

• Voltage grade up to 1100 volts
• Conductor: Bare EC Copper /Nickel Plated Copper/ Silver Plated Copper
• Type: Multi stranded flexible
• Core insulation: Sintered PTFE / Fiber Glass with high temperature varnish
• Construction: Twisted Cores / Laid up cores
• Inner jacket: Sintered PTFE & then Glass Plated Mica Tape
• Outer jacket: Fiber Glass Braiding / Asbestos Yarn Braiding
• Metal braiding: Stainless Steel wire mesh for Mechanical protection [Optional]

Other Options

• Aluminium mylar tape Shield / Screen with ATC drain wire
• Overall Asbestos Braiding for Better Chemical & Heat Resistance
• Colour coding as per customer requirement
• Sizes available: 0.5 / 1 /1.5 / 2.5 / 4 / 6 / 10 / 16 / 25 sq.mm.
• Number of cores available: 1C to multicore as per customer requirement
• Standards applicable: IS: 8130, IS: 1554 (Pt-1), JSS : 51034, BS : 5308 (Pt-1)

HTC-927-400

Sintered PTFE – Sintered PTFE – Mica – Fiber Glass – S.S. Wire

Specification

• Voltage grade : up to 1100 volts
• Conductor: Bare Copper / Nickel Plated Copper / Silver Plated Copper
• Type: Multi stranded Flexible
• Core Insulation : Sintered PTFE with Kapton
• Construction : Twisted core / Laid up Cores
• Inner jacket :  Sintered PTFE Tape then Glass Mica Tape
• Outer jacket : Glass Mica Tape and then Fiber Glass with high temperature varnish
• Metal Braiding : Stainless Steel wire mesh for Mechanical protection [Optional]

Other Options

• Aluminium mylar tape Shield / Screen with ATC drain wire
• Overall Asbestos Braiding for Better Chemical & Heat Resistance
• Colour coding as per customised requirement
• Sizes available: 0.5 / 1 /1.5 / 2.5 / 4 / 6 / 10 / 16 / 25 sq.mm.
• Number of cores available: 1C to Multicore as per customer requirement
• Standards applicable: IS: 8130, IS: 1554 (Pt-1), JSS : 51034, BS : 5308 (Pt-1)

HTC-936-500

Sintered PTFE – Fiber Glass – Mica – Fiber Glass – S.S. Wire

Specification

• Voltage grade : up to 1100 volts
• Conductor: Bare Copper / Nickel Plated Copper / Silver Plated Copper
• Type : Multi stranded
• Core Insulation : Mica / Sintered PTFE / Kapton Fiber Glass with high temperature varnish
• Construction : Twisted core / laid up cores
• Inner jacket :  Glass Plated Mica Tape and then Fiber Glass with high temperature varnish
• Outer jacket :  Fiber Glass then Asbestos Yarn Braiding
• Metal Braiding : Stainless Steel wire mesh for Mechanical protection [Optional]

Other Options

• Aluminium mylar tape Shield / Screen with ATC drain wire
• Overall Asbestos Braiding for Better Chemical & Heat Resistance
• Colour coding as per customised requirement
• Sizes available: 0.5 / 1 /1.5 / 2.5 / 4 / 6 / 10 / 16 / 25 sq.mm.
• Number of cores available: 1C to Multicore as per customer requirement
• Standards applicable: IS: 8130, IS: 1554 (Pt-1), JSS : 51034, BS : 5308 (Pt-1)

HTC-945-600

High Temperature Copper Power Cable suitable for 600 deg C

Specification

• Voltage grade : up to 1100 volts
• Conductor: Multi stranded Annealed Electrolytic grade copper as per class – 5 of IS:8310-1984
• Primary Insulation: Mica tape then Sintered Teflon (PTFE) with Kapton
• Secondary Insulation : Heat & flame Resistant double Fiber Glass covering with heat resistance varnish
• Core Laying: Core Laid up together
• Inner Sheath: Sintered Teflon (PTFE)
• Outer Sheath: Double Mica tape, Double Fiber Glass Braiding, Asbestos Braiding
• Mechanical Protection : Stainless Steel Braided to protect the cable from Mechanical Stress
• Sizes available: 0.5 / 1 /1.5 / 2.5 / 4 / 6 / 10 / 16 / 25 sq.mm. from single core to multi core
• Standards applicable: IS: 8130, IS: 1554 (Pt-1), JSS : 51034, BS : 5308 (Pt-1)
